Detailed instructions to adjust the travel distance and speed of the Pro Edge. See also Service Guide SG0400 for additional information on setting the Denison Card.

Speeds and distance.

Set the limit flags so the cross travel will have 10 feet of actual travel. Set the cross travel speed to 100 (high side). On max speed, the 10 feet of travel should take 6 seconds. You will need to adjust A max, and B max for the appropriate direction. Turning the adjustment screw clockwise will increase the speed, and counter clockwise will decrease the speed. NOTE: be sure both directions are set to the correct speed.

Check initial settings

Once the high side is done, set the cross travel speed to 10 (low side), and set the limit flags for 2.5 feet of actual travel. On low speed, the 2.5 feet of travel should take approximately 15 to 16 seconds. Again, adjust the A min and B min for the appropriate
direction. NOTE: be sure both directions are set to the correct speed.

Repeat step 1.

Once the low side is set, you will need to go back and repeat step 1. By adjusting either the high side or low side, it will affect the other. You may need to go back and forth between the high side and low side several times, until they are both set accordingly.

ramping up and down

Once ALL the speeds have been set properly, we will need to set the Ramp up and Ramp down. (NOTE: these are the bottom two screws noted by the line with an up angle, and the line with the down angle.) The ramp down (line with angle down) will determine how far the cross travel will run onto the limit flag. By adjusting the screw clockwise, the cross travel will move farther onto the limit flag. Set it so the cross travel stops about 3/4 of the way onto the limit flag at max speed.

Fine tuning the ramping

Now you will need to adjust the ramp up (the line with the angle up) to make a smooth transition from one direction to the other. Begin by turning the adjustment screwclockwise. NOTE: your cross travel speed should still be at 100. You should note the
cross travel stopping and starting in a smooth motion. If you adjust the screw to far in the clockwise direction, it will start to become a sudden stop and start again. Simply start to go counter clockwise until you reach a smooth stop and start motion.

Double checking all settings

Once you have everything adjusted, you may want to go back and repeat steps 1 through 5, to make sure nothing has changed
