This is a quick reference guide that will help you find service guides for the Saberjet XP.
Scan to view on mobile device
Machine Manual
The operation and maintenance manual for the SABERjet XP CNC Sawjet from Park Industries®. This manual applies to both single and two table machine configurations.
Machine Software
In this video, we will show you how to identify areas that could cause a 8258 target position or software limit alarm.
This guide will help you restore the values on your machine if they got erased out. This guide is for Saberjets that are running Hypervisor/Windows 10. 1013: Axis/Axes not referenced alarm.
Nozzle Broke Alarm
If you have the nozzle broke alarm but the nozzle is not broke then the prox could be bad. This guide will show you how to bypass the prox until you can get a new one. This guide was made on a Javelin. Your setup may look a little different.
Water Flow Alarm
This video will show you how to clean the water flow sensor.
This video is made on a Voyarger saw but is the same concept as a Saberjet XP.
Z Axis
Walk through with a Park Industries Customer Service Rep how to perform an advanced blade touch off for accurate miter and straight cuts.
This video shows you how to calibrate the material height sensor.
This video is done on a Javelin but is the same concept on the Saberjet XP. The calibrate button is in the setup screen
Machine Calibration
This video will show how to do the blade offset cut. This is one of the first things to do when you change a blade, or experience issues with blade to router alignment. This tells the machine what the offset is when it rotates C from 0 to 180. This number changes with each blade and over time. Anytime you are having issues with cut sizing this is the first step to go to.
Miter Cut Issues
This guide is a list of steps you will want to go through to ensure your miter cuts are the correct size.
Dialing
This video shows how to dial that A and C axis then dial the machine offsets.
Y Axis
In this video we will show you how to check and set the Y axis backlash on Saberjet XP.
In this video we will show you the process of replacing the Y axis drive gears on a Saberjet XP.
In this video we will show you how to square the bridge for Saberjet XP. Bridge can become skewed if crashed hard enough or in the event of changing out a pinion gear, bearing, rails or gear rack.
Grease Malfunction
This video will go through how to diagnose grease flow issues on the Sabertet.
This video is on the Voyager but is the same concept as the Saberjet XP.
