Spindle Motor replacement

Guide Number: SG1257 | Printer Friendly Version | View Safety Disclaimer

This document illustrates the steps necessary to properly replace a spindle motor on a Park Industries Fastback machine.

Skill level 2

estimated time to complete: 30 minutes

  1. Power down the machine at the wall. Follow your companies internal lockout/tagout procedures.
  2. Open the junction box on the motor, make sure to label the wires then disconnect the wiring and remove the power cord from the motor.
  1. Remove the three (3) set screws from the coupler, then remove the coupler from the motor shaft.
  1. Remove all four bolts securing the motor to the bridge plate, support the motor from under to keep from falling then pull the motor down and out through the bottom of the bridge. Install the new spindle motor in reverse order. Fill cavity with grease to keep water out

Last updated: November 30, 2020
