This is a quick reference guide that will help you find service guides for the Voyager.
Scan to view on mobile device
Machine Manual
The operation and maintenance manual for the VOYAGER XP from Park Industries®.
Machine Software
In this video, we will show you how to identify areas that could cause a 8258 target position or software limit alarm.
This guide will help you restore the values on your machine if they got erased out. This guide is for Voyager that are running Hypervisor/Windows 10. 1013: Axis/Axes not referenced alarm.
Water Flow Alarm
Alarm: 1006, 1005, 700232, 700233, Recycled, Fresh, Spindle Ring Water Feed Low, Spindle Center water Feed Low, Fresh Water Low Flow, Recycled Water Low Flow, Insufficient Water Flow
Table Planing
In this video, you will learn the procedure for planing the concrete table of the Voyager saw. Watch the step by step how to guide.
Z Axis
Walk through with a Park Industries Customer Service Rep how to perform an advanced blade touch off for accurate miter and straight cuts.
This video is done on a Saberjet but is the same concept on the Voyager.
This video shows you how to calibrate the material height sensor.
This video is done on a Javelin but is the same concept on the Voyager. The calibrate button is in the setup screen
Blade Offset Calibration
This video will show how to do the blade offset cut. This is one of the first things to do when you change a blade, or experience issues with blade to router alignment. This tells the machine what the offset is when it rotates C from 0 to 180. This number changes with each blade and over time. Anytime you are having issues with cut sizing this is the first step to go to.
This video is done on a Saberjet but is the same concept on the Voyager.
Miter Cut Issues
This guide is a list of steps you will want to go through to ensure your miter cuts are the correct size.
Dialing
Video showing how to dial the blade A and C on a Voyager.
Y axis
In this video we will show you how to check and set the Y axis backlash on Voyager XP.
This video is done on a Saberjet but is the same concept on the Voyager.
In this video we will show you the process of replacing the Y axis drive gears on a Voyager XP.
This video is done on a Saberjet but is the same concept on the Voyager.
In this video we will show you how to square the bridge for Voyager XP. Bridge can become skewed if crashed hard enough or in the event of changing out a pinion gear, bearing, rails or gear rack.
This video is done on a Saberjet but is the same concept on the Voyager.
Grease Malfunction
This video will go through how to diagnose grease flow issues on the Voyager.
